DragonPlate carbon fiber corner gussets provide a simple method to bond together flat stock, enabling the creation of various structures using carbon fiber sheets. They are molded to 90-degree angles, which simplifies assembly and eliminates the need for extra tube or beam supports. These gussets are ideal for fixture creation and structural reinforcement in lightweight, high-strength applications.
DragonPlate offers corner gussets in two thicknesses: 1/16" (0.0625") and 1/32" (0.03125"). Available sizes include 3 3/8" and 6 3/8" lengths. Each gusset features a texture/texture finish for optimal bonding. Example SKUs and prices: FDPCG023D*1*90 (1/16" x 3 3/8", $83.25), FDPCG023D*2*90 (1/16" x 6 3/8", $108.00), FDPCG013D*1*90 (1/32" x 3 3/8", $67.00), FDPCG013D*2*90 (1/32" x 6 3/8", $92.75).
DragonPlate corner gussets are designed with a texture by texture finish for an ideal bonding surface. They utilize a quasi-isotropic, symmetrical layup schedule and a rigid epoxy matrix. For assembly, DragonPlate recommends using the Scotchweld #2216 epoxy adhesive kit, which offers extremely high shear and peel strengths for structural bonding.
Yes, DragonPlate corner gussets are designed to work with DragonPlate carbon fiber sheets and square tubing. They can also serve as an alternative to the three-way corner gusset for certain structural configurations, providing flexibility in assembly options.
CAD models for all DragonPlate carbon fiber corner gussets are available for download directly from the product page. This allows designers and engineers to integrate gussets into their projects efficiently. Download All Carbon Fiber Corner Gusset CAD Models
Carbon Fiber gussets allow for a simple method to bond together flat stock. This is a simple way to create an array of structures using DragonPlate carbon fiber sheets, eliminating the extra cost unnecessary tube or beam supports. Our corner gussets are already molded to 90 degree angles, which will save much time and energy in assembly and the creation of fixtures. Our carbon fiber corner gusset can also work well with our square tubing as an alternative to our three way corner gusset. These carbon fiber gussets are made with a texture by texture finish for an ideal bonding surface, utilizing a quasi-isotropic, symmetrical lay up schedule and a rigid epoxy matrix. Our gusset plates have been designed to work with our Scotchweld #2216 epoxy adhesive kit. This is an ideal structural adhesive with extremely high shear and peel strengths.
Download All Carbon Fiber Corner Gusset CAD Models
SKU | DESCRIPTION | FINISH | THICKNESS | PRICE | ||
 FDPCG023D*1*90 | 1/16" x 3 3/8" Corner Gusset | Texture/Texture | 0.0625" | $83.25 | ||
 FDPCG023D*2*90 | 1/16" x 6 3/8" Corner Gusset | Texture/Texture | 0.0625" | $108.00 | ||
 FDPCG013D*1*90 | 1/32" x 3 3/8" Corner Gusset | Texture/Texture | 0.03125" | $67.00 | ||
 FDPCG013D*2*90 | 1/32" x 6 3/8" Corner Gusset | Texture/Texture | 0.03125" | $92.75 |
| ||||||||||||||
| ||||||||||||||
| ||||||||||||||
| ||||||||||||||
