    High Modulus Carbon Fiber Sheets

    Dragonplate high modulus carbon fiber sheets are fabricated using a special type of uni-directional prepreg fiber that is processed to have a stiffness almost double that of our standard uni prepreg sheets and about 2.5 times as stiff as our standard solid Dragonplate. Twill/Uni sheets are available in a satin finish on both sides. Uni sheets are only available in a textured finish on both sides. Although more expensive than our other carbon fiber options, this material is about 50% stiffer than aluminum, but at half the weight, providing an opportunity for unprecedented weight savings in applications where minimum panel thickness, weight, and deflection are critical. Our standard offering includes a few select panel thicknesses; however, we are able to custom fabricate these plates up to 30"x40" and 1/2" thick upon request. High modulus sheets are made to order and therefore are not returnable.

    Please allow 10-15 days before this product ships

    View as Grid List Table
    Sort by
    Display per page

    SKU

    DESCRIPTION

    SHEET SIZE

    SHEET THICKNESS

    PLY ORIENTATION

    PRICE

    FDPLHI-MOD02S*TWL*901

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 12"

    12" x 12" 1/16" Woven 0/90 and UD 0 and 90 $120.00

    FDPLHI-MOD02S*TWL*901

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 24"

    12" x 24" 1/16" Woven 0/90 and UD 0 and 90 $225.00

    FDPLHI-MOD02S*TWL*902

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 24"

    24" x 24" 1/16" Woven 0/90 and UD 0 and 90 $415.00

    FDPLHI-MOD02S*TWL*902

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 36"

    24" x 36" 1/16" Woven 0/90 and UD 0 and 90 $575.00

    FDPLHI-MOD02T*90*1212

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 12" x 12"

    12" x 12" 1/16" Woven 0/90 and UD 0 and 90 $120.00

    FDPLHI-MOD02T*90*1224

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 12" x 24"

    12" x 24" 1/16" Woven 0/90 and UD 0 and 90 $225.00

    FDPLHI-MOD02T*90*2424

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 24" x 24"

    24" x 24" 1/16" Woven 0/90 and UD 0 and 90 $415.00

    FDPLHI-MOD02T*90*2436

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 24" x 36"

    24" x 36" 1/16" Woven 0/90 and UD 0 and 90 $575.00

    FDPLHI-MOD02S1212

    1/16" Quasi-isotropic Carbon Fiber High Modulus Uni Sheet - 12" x 12"

    12" x 12" 1/16" UD 0 and 90 and ±45 $225.00

    FDPLHI-MOD08S*TWL*902

    1/4" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 24"

    24" x 24" 1/4" Woven 0/90 and UD 0 and 90 $1,225.00

    FDPLHI-MOD08S*TWL*902

    1/4" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 36"

    24" x 36" 1/4" Woven 0/90 and UD 0 and 90 $1,700.00

    FDPLHI-MOD04S*TWL*901

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 12"

    12" x 12" 1/8" Woven 0/90 and UD 0 and 90 $188.00

    FDPLHI-MOD04S*TWL*901

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 24"

    12" x 24" 1/8" Woven 0/90 and UD 0 and 90 $350.00

    FDPLHI-MOD04S*TWL*902

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 24"

    24" x 24" 1/8" Woven 0/90 and UD 0 and 90 $645.00

    FDPLHI-MOD04S*TWL*902

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 36"

    24" x 36" 1/8" Woven 0/90 and UD 0 and 90 $895.00
    Sku: FDPLHI-MOD02S*TWL*901
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 12"

    Sheet Size: 12" x 12"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $120.00
    Sku: FDPLHI-MOD02S*TWL*901
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 24"

    Sheet Size: 12" x 24"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $225.00
    Sku: FDPLHI-MOD02S*TWL*902
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 24"

    Sheet Size: 24" x 24"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $415.00
    Sku: FDPLHI-MOD02S*TWL*902
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 36"

    Sheet Size: 24" x 36"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $575.00
    Sku: FDPLHI-MOD02T*90*1212
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 12" x 12"

    Sheet Size: 12" x 12"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $120.00
    Sku: FDPLHI-MOD02T*90*1224
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 12" x 24"

    Sheet Size: 12" x 24"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $225.00
    Sku: FDPLHI-MOD02T*90*2424
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 24" x 24"

    Sheet Size: 24" x 24"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $415.00
    Sku: FDPLHI-MOD02T*90*2436
    Name:

    1/16" 0/90 Carbon Fiber High Modulus Uni Sheet - 24" x 36"

    Sheet Size: 24" x 36"
    Sheet Thickness: 1/16"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $575.00
    Sku: FDPLHI-MOD02S1212
    Name:

    1/16" Quasi-isotropic Carbon Fiber High Modulus Uni Sheet - 12" x 12"

    Sheet Size: 12" x 12"
    Sheet Thickness: 1/16"
    Ply Orientation: UD 0 and 90 and ±45
    Price: $225.00
    Sku: FDPLHI-MOD08S*TWL*902
    Name:

    1/4" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 24"

    Sheet Size: 24" x 24"
    Sheet Thickness: 1/4"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $1,225.00
    Sku: FDPLHI-MOD08S*TWL*902
    Name:

    1/4" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 36"

    Sheet Size: 24" x 36"
    Sheet Thickness: 1/4"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $1,700.00
    Sku: FDPLHI-MOD04S*TWL*901
    Name:

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 12"

    Sheet Size: 12" x 12"
    Sheet Thickness: 1/8"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $188.00
    Sku: FDPLHI-MOD04S*TWL*901
    Name:

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 12" x 24"

    Sheet Size: 12" x 24"
    Sheet Thickness: 1/8"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $350.00
    Sku: FDPLHI-MOD04S*TWL*902
    Name:

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 24"

    Sheet Size: 24" x 24"
    Sheet Thickness: 1/8"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $645.00
    Sku: FDPLHI-MOD04S*TWL*902
    Name:

    1/8" 0/90 Carbon Fiber High Modulus Twill/Uni Sheet - 24" x 36"

    Sheet Size: 24" x 36"
    Sheet Thickness: 1/8"
    Ply Orientation: Woven 0/90 and UD 0 and 90
    Price: $895.00
