What are DragonPlate Modular Carbon Fiber Tube Connectors?
DragonPlate Modular Carbon Fiber Tube Connectors are lightweight, patented anodized aluminum connectors designed to join round carbon fiber tubes into complex, rigid structures. They enable users to assemble and disassemble tubes quickly, forming both 2D and 3D frameworks without the need for drilling, screwing, or complex fixturing. These connectors are compatible with 0.5", 0.625", 0.75", 0.875", and 1" inner diameter carbon fiber tubes. Note: Only compatible with specified tube sizes; not suitable for tubes outside these dimensions.
What tube sizes are compatible with DragonPlate modular connectors?
DragonPlate modular connectors are compatible with round carbon fiber tubes having inner diameters of 0.5", 0.625", 0.75", 0.875", and 1". Note: These connectors are not designed for tube sizes outside this range.
What types of structures can be built with DragonPlate modular connectors?
With DragonPlate modular connectors, users can create both simple and complex 2D and 3D structures, including long, disassemblable tubes and multi-joint frameworks. The system supports unlimited joint connections, making it suitable for applications requiring modularity and reconfiguration. Note: The system is optimized for use with DragonPlate's specified tube sizes and may not be suitable for non-standard tube geometries.
How do you assemble DragonPlate modular tube connectors?
To assemble, lightly sand the inside of the carbon fiber tube, apply adhesive, and insert the connector. No complex fixturing, screwing, or drilling is required. This process creates a strong joint without weakening the tube. Note: Proper adhesive selection and surface preparation are critical for optimal joint strength; consult DragonPlate's technical documentation for best practices.
What connector types and configurations are available?
DragonPlate offers a wide range of modular connector types, including 90-degree tangent tube mounts, end connector blanks, female and male clevis connectors (with and without end threads), modular 6-way cubes, and pultruded tube end connectors. These are available in various lengths and finishes, with prices starting from $7.10 for a 0.5" Modular 6-Way Cube. Note: Availability may vary by size and configuration; check the product catalog for current options.
Pricing & Plans
What are the prices for DragonPlate modular tube connectors?
Prices for DragonPlate modular tube connectors vary by type and size. For example, a 0.5" Carbon Fiber 90 Degree Tangent Tube Mount™ - 3" Long is $28.50, while a 0.5" Modular 6-Way Cube starts at $7.10. End connector blanks and clevis connectors start from $7.70. Note: Prices are subject to change and may vary by configuration; see the product page for the latest pricing.
Features & Capabilities
What are the main benefits of using DragonPlate modular connectors?
Key benefits include simple and fast assembly, strong joints without drilling or weakening tubes, compatibility with multiple tube sizes, the ability to create complex and reconfigurable structures, and the option to disassemble and reassemble as needed. The system avoids the need for welding or specialty bonding, reducing labor and tooling requirements. Note: For applications requiring permanent, high-load joints, alternative joining methods may be more suitable; consult engineering guidance for load-critical designs.
How do DragonPlate modular connectors compare to traditional joining methods?
DragonPlate modular connectors allow for assembly without drilling, screwing, or welding, which preserves tube strength and simplifies construction. Traditional methods often require drilling or bolting, which can weaken the tube and increase assembly time. The modular system is designed for rapid assembly and disassembly, making it ideal for prototyping and modular builds. Note: For permanent, load-bearing joints, traditional methods may still be preferred; always evaluate based on application requirements.
Are DragonPlate modular connectors patented?
Yes, DragonPlate modular connectors are protected under U.S. Patent #9,803,672 B2. This patent covers the unique design and assembly method of the modular connector system. Note: Patent protection applies to the connector design and assembly process; always verify compatibility with your intended use.
Technical Requirements & Documentation
Where can I find technical documentation and CAD models for DragonPlate modular connectors?
Technical documentation, including CAD models, installation guides, and specifications, can be downloaded from the DragonPlate CAD Models page and the Weights and Specs page. For adhesive recommendations and assembly instructions, refer to the product-specific documentation or contact DragonPlate support. Note: Always use the latest documentation for your specific connector model.
What adhesives are recommended for assembling modular connectors?
DragonPlate recommends using high-quality structural adhesives, such as those from 3M or LOCTITE/Hysol, for assembling modular connectors. Specific adhesive selection depends on the application and materials; refer to the 3M Adhesives Catalog or LOCTITE/Hysol Adhesives for guidance. Note: Improper adhesive selection or surface preparation can compromise joint strength; always follow manufacturer recommendations.
Use Cases & Benefits
Who can benefit from using DragonPlate modular connectors?
Engineers, product designers, researchers, and procurement managers in industries such as aerospace, robotics, industrial automation, and research institutions can benefit from DragonPlate modular connectors. The system is ideal for projects requiring lightweight, strong, and easily reconfigurable structures. Note: For applications outside these industries, suitability should be evaluated based on specific project requirements.
What problems do DragonPlate modular connectors solve?
DragonPlate modular connectors address challenges such as complex assembly processes, the need for rapid prototyping, and the difficulty of joining carbon fiber tubes without weakening them. They eliminate the need for welding, drilling, or specialty bonding, reducing labor and tooling costs. Note: For applications requiring permanent, high-load joints, alternative solutions may be more appropriate; consult engineering support for guidance.
Support & Implementation
How quickly can I implement DragonPlate modular connectors in my project?
Implementation is typically fast, as the connectors are designed for easy assembly with minimal tools. Prefabricated components and clear documentation allow for immediate integration into projects. For custom requirements, DragonPlate offers CNC cutting and design services. Note: Lead times may increase for custom or bulk orders; contact DragonPlate for details.
Where can I get support or ask technical questions about modular connectors?
For technical support, contact DragonPlate via phone at 315-252-2559 (Monday–Friday, 8:30am–5:00pm ET) or email at service@dragonplate.com. Additional resources, including FAQs and technical guides, are available on the DragonPlate FAQ page. Note: For highly specialized or regulated applications, consult with DragonPlate engineering for compliance and suitability.
Compliance & Certifications
Are DragonPlate modular connectors manufactured under quality standards?
Yes, all DragonPlate products, including modular connectors, are manufactured under ISO 9001:2015 quality standards at the company's facility in Elbridge, New York. This ensures consistent quality and reliability. Note: ISO certification covers manufacturing processes; always verify product suitability for your specific application.
